Massey Ferguson 1462 Front End Loader Specs

Compatible Tractors

Tractor model .......... MF 1417, 1423
Front tires .......... 6.00x14
Rear tires .......... 12.0-16.5
Pump capacity, gpm (lpm) .......... 5.4 (20.3)

Standard Material Bucket

Width, in (mm) .......... 48 (1220)
Struck capacity, ft3 (m3) .......... 5,67 (0,16)
Heaped capacity, ft3 (m3) .......... 7,02 (0,20)

Massey Ferguson 1462 Loader Dimensions

Maximum lift height at Pivot Pin, in (mm) .......... 74 (1870)
Clearance at full height, bucket dumped, in (mm) .......... 53 (1340)
Clearance with level bucket, in (mm) .......... 68 (1720)
Reach at maximum height, in (mm) .......... 22 (550)
Reach at ground, bucket level, in (mm) .......... 51 (1290)
Bucket dump angle, degrees .......... 51
Bucket rollback angle, degrees .......... 23

Massey Ferguson 1462 Loader Operating Specifications

Lift Capacity to Maximum Height at Pivot Pin, lbs (kg) .......... 800 (362)
Breakout Force at Pivot Pin, lbs (kg) .......... 965 (437)

Cycle Times

Loader Raise, sec .......... 6,1
Loader Lower, sec .......... 4,1
Bucket Dump, sec .......... 4,8
Bucket Rollback, sec .......... 4,3
